IPV-4K24U

Regular price Rs.10,000.00

Category Specification Details Type IPL-51100 Battery Type LiFePO₄ Nominal Voltage 51.2V Nominal Capacity (Wh) 5.12kWh Nominal Capacity (Ah) 100Ah Operating...

Color :

White

Model :

IPV-4K24U

I agree with the terms and conditions

Wishlist Compare

Vendor: Itel

Type: N/a

Sku: N/a

Free shipping

Secure payment

Best Warrenty

Shipping information

Only For Karachi

👀 customers are viewing this product

🔥 13 sold in last 18 hours

Guarantee safe checkout

IPV-4K24U - White / IPV-4K24U

Rs.10,000.00

Color

Model

Description Material Reviews

Category	Specification	Details
Type		IPL-51100
Battery Type		LiFePO₄
Nominal Voltage		51.2V
Nominal Capacity (Wh)		5.12kWh
Nominal Capacity (Ah)		100Ah
Operating Voltage Range		40V–58.4V
Standard Charging Current		50A
Maximum Continuous Charge Current		100A
Cut-off Charging Voltage		58.4V
Cut-off Charging Current		2A
Standard Discharge Current		50A
Maximum Continuous Discharge Current		100A
Maximum Pulse Discharge Current		150A
Cut-off Discharge Voltage		40V
Cut-off Discharge Current		2A
Dimensions (mm)		460×510×153
Weight (kg)		50
Communication Port		RS485 / RS232 / CAN
Working Temperature (Charge)		-0°C to 55°C
Working Temperature (Discharge)		-20°C to 60°C
Ingress Protection		IP21
Cooling Type		Natural Cooling
Humidity		0%–95%
Altitude (m)		<2000
Shell Material		Metal
Current Limiting Function		Limited 10A
Precharge Function		Enable
Display Mode		4 Green LED
Design Life		10+ Years
Cycle Life		≥6000
Authentication Level		IEC + UN38.3 + MSDS + DGM

You now have three battery models extracted:

IPW-25100
IPW-51100
IPL-51100
