MODEL NO. ZING-TC-11K

Rs.10,000.00
Regular price ~~Rs.20,000.00~~

Section Specification Features • High frequency inverter • Lighter weight with higher efficiency • Output power factor PF=1 • Lithium...

MODEL NO. :

ZING-TC-11K

I agree with the terms and conditions

Wishlist Compare

Vendor: Zing

Type: N/a

Sku: N/a

Free shipping

Secure payment

Best Warrenty

Shipping information

Only For Karachi

👀 customers are viewing this product

🔥 13 sold in last 18 hours

Guarantee safe checkout

MODEL NO. ZING-TC-11K - ZING-TC-11K

Rs.10,000.00

MODEL NO.

Description Material Reviews

Section	Specification
Features	• High frequency inverter • Lighter weight with higher efficiency • Output power factor PF=1 • Lithium battery activation start function with & without solar mode • Parallel function to expand power • Higher solar charging efficiency and battery protection • Pure sine wave output, adaptable to different loads • 500V high PV input • WiFi function • Working with or without battery
INPUT	Phase: 1-Phase Nominal Voltage: 220/230/240VAC Voltage Range: 145-280VAC ±5VAC (Normal Mode), 85-280VAC ±5VAC (UPS Mode) Frequency Range: 50Hz/60Hz (Auto Sensing)
OUTPUT	Rated Power: 11KW Output Voltage (AC): 208/220/230/240VAC ±5% Output Frequency: 50Hz/60Hz Waveform: Pure sine wave Transfer Time (Optional): 10ms for computers, 20ms for home appliances Peak Power: 2× rated power
OVERLOAD	Battery Mode: 1min (110%~150% Load) 10s (150%~200% Load) 200ms (≥200% Load)
BATTERY	Rated Voltage: 48Vdc Constant Voltage Charging Voltage (Optional): 54Vdc Floating Charging Voltage (Optional): 52Vdc
CHARGER	PV Charging Method: MPPT Nominal Voltage Max PV: 500Vdc Charging Current Max PV: 150A Charging Current Max AC: 60A Charging Current Max AC+PV: 150A Max Charging Current: 150A
DISPLAY	LCD Display: Operating mode / input / output / PV / battery etc.
COMMUNICATION PORT	RS232: Standard configuration RS485/WiFi: Optional (communication card, WiFi card, dry contact card) Parallel installation: YES
ENVIRONMENTAL PARAMETERS	Operating Environment Temp: -15℃ ~ +60℃ Relative Humidity: 0–95% (non-condensing) Storage Temperature: -15℃ ~ +60℃ Noise (dB): 60dB~63dB Altitude: ≤1000m, derating when >1000m (≤4000m, refer to IEC62040-3)
CERTIFICATION	EN/IEC 62040-1, EN/IEC 62109-1/2, CE, IEC 61000-6-1/3
INGRESS PROTECTION	IP21
